Pad Printing machine TIC 201 SCDEL-XXL Special

Prices after login !!!

Product No.: 16005201SCDEL-XXL
Print product data sheet

Delivery time:

on request

Pad Printing machine TIC 201 SCDEL-XXL Special

1-colour-machine, stand model, electro pneumatic control, closed ink system with transversal movement, ink cup ø: 90mm, cliché size 100x583mm, touch-panel operation, special model with increased pad stroke = 380mm, pad pressure 168kgs when 6bar. Needed connection: 230volts, 50cycles, compressed air 6bar.

Sturdy housing made of aluminium cast, electro-pneumatic control, clear display with modern microprocessor control, optional signal outputs for connection of peripherals. Stand models with sturdy torsion-resistant support out of steel plate with an extended downward adjustment of the feeding table to positioning of higher objects. European/Japanese pneumatic elements, low running by air sound absorbers, pad pressure adjustable via display, closed ink system with register pins for magnetic fastening, ink cups with ceramic doctor rings, contact pressure adjustable via magnetic adjustment. All machines equipped with safety plates at the sides as well as emergency switch and foot switch.
